Nibe F1145-17 665209

Here you'll find our primary range for Nibe F1145-17 665209. If you can't find the spare part you're looking for, please contact us by phone, chat or email and we'll help you find the right spare part and see if it's available.

All our spare parts for Nibe F1145 are original from Nibe and have 12 month warranty.

Sprängskisser

Klicka för att förstora

Nibe F1145-17 665209

Products

  1. 001. Immersion heater, 3x400

    Immersion heater, 3x400
    421.07£ incl. VAT 336.86£ excl. VAT Add to Cart
  2. 002. Circuit-breaker Moeller

    Circuit-breaker Moeller
    18.89£ incl. VAT 15.11£ excl. VAT Add to Cart
  3. 005. Thermostat limiter

    Thermostat limiter
    104.13£ incl. VAT 83.30£ excl. VAT Add to Cart
  4. 007. Schrader valve 1/4

    Schrader valve 1/4
    16.77£ incl. VAT 13.41£ excl. VAT Add to Cart
  5. 008. Drain valve, heating system

    Drain valve, heating system
    20.10£ incl. VAT 16.08£ excl. VAT Add to Cart
  6. 011. Transformer, 3 pcs/package

    Transformer, 3 pcs/package
    51.71£ incl. VAT 41.37£ excl. VAT Add to Cart
  7. 015. Room sensor RTS 40 NIBE, usage for both outdoor and room

    The RTS 40 sensor is Nibe's standard sensor and is used as both an outside sensor and room sensor for several of Nibe's heat pumps and electric boilers.


    This sensor is the same as Nibe 218845, Nibe has just made some minor changes in the encapsulation to improve its durability.
    37.47£ incl. VAT 29.98£ excl. VAT Add to Cart
  8. 016. Circulation pump

    Circulation pump
    708.11£ incl. VAT 566.49£ excl. VAT Add to Cart
  9. 017. Evaporator

    Evaporator
    1,033.43£ incl. VAT 826.75£ excl. VAT Add to Cart
  10. 018. Condenser

    Condenser
    1,017.78£ incl. VAT 814.22£ excl. VAT Add to Cart
  11. 019. 3-way valve, Ø28

    3-way valve, Ø28
    192.10£ incl. VAT 153.68£ excl. VAT Add to Cart
  12. 021. Shutoff valve

    Shutoff valve
    53.63£ incl. VAT 42.90£ excl. VAT Add to Cart
  13. 022. Shutoff valve

    Shutoff valve
    53.63£ incl. VAT 42.90£ excl. VAT Add to Cart
  14. 023. Drain pipe

    Drain pipe
    16.77£ incl. VAT 13.41£ excl. VAT Add to Cart
  15. 026. Circuit breaker Pkzm0-16

    Circuit breaker Pkzm0-16
    126.76£ incl. VAT 101.40£ excl. VAT Add to Cart
  16. 027. Compressor 17kW

    Compressor 17kW
    2,335.63£ incl. VAT 1,868.50£ excl. VAT Add to Cart
  17. 029. Immersion heaters 3x400V

    Immersion heater 3x400V
    162.71£ incl. VAT 130.17£ excl. VAT Add to Cart
  18. 031. Inlet card

    Inlet card
    203.62£ incl. VAT 162.89£ excl. VAT Add to Cart
  19. 032. Display module, heavy

    Display unit, heavy
    393.90£ incl. VAT 315.12£ excl. VAT Add to Cart
  20. 033. High pressure pressostat

    High pressure pressostat
    29.69£ incl. VAT 23.76£ excl. VAT Add to Cart
  21. 034. Base card

    Base card
    265.13£ incl. VAT 212.10£ excl. VAT Add to Cart
  22. 035. Circulation pump UPMXL Geo 25-125 180 mm

    Circulation pump UPMXL Geo 25-125 180mm
    679.48£ incl. VAT 543.58£ excl. VAT Add to Cart
  23. 041. Low pressure pressostat

    Low pressure pressostat
    27.27£ incl. VAT 21.82£ excl. VAT Add to Cart
  24. 042. Schrader valve 1/4

    Schrader valve 1/4
    16.77£ incl. VAT 13.41£ excl. VAT Add to Cart
  25. 043. Motor for 3-way valve

    Motor for 3-way valve
    142.61£ incl. VAT 114.09£ excl. VAT Add to Cart
  26. 044. Foot Ø38 M10

    Foot Ø38 M10
    16.77£ incl. VAT 13.41£ excl. VAT Add to Cart
  27. 045. Knob

    Knob
    16.77£ incl. VAT 13.41£ excl. VAT Add to Cart
  28. 046. Shutoff valve

    Shutoff valve
    53.63£ incl. VAT 42.90£ excl. VAT Add to Cart
  29. 048. Expansion valve, Flica R407c

    Expansion valve, Flica R407c
    195.44£ incl. VAT 156.35£ excl. VAT Add to Cart
  30. 051. Drain valve, heating system

    Drain valve, heating system
    20.10£ incl. VAT 16.08£ excl. VAT Add to Cart
  31. 052. Safety valve 3,0bar

    Safety valve 3,0bar
    57.67£ incl. VAT 46.14£ excl. VAT Add to Cart
  32. 062. Flexible pipe

    Flexible pipe
    110.39£ incl. VAT 88.31£ excl. VAT Add to Cart
  33. 063. Filter ball

    Particle filter R25
    44.14£ incl. VAT 35.31£ excl. VAT Add to Cart
  34. 064. Filter ball R32

    Particle filter R32
    64.14£ incl. VAT 51.31£ excl. VAT Add to Cart
  35. 065. Filter drier, Benchmark

    Drying filter, Benchmark
    58.08£ incl. VAT 46.46£ excl. VAT Add to Cart
  36. 066. Ball valve

    Ball valve
    45.25£ incl. VAT 36.20£ excl. VAT Add to Cart
  37. 067. Contactor DILMC15-10

    Contactor DILMC15-10
    79.08£ incl. VAT 63.27£ excl. VAT Add to Cart
  38. 068. Contactor DILMC15-10

    Contactor DILMC15-10
    79.08£ incl. VAT 63.27£ excl. VAT Add to Cart
  39. 069. Lock clip 4pcs / package

    Lock clip 4pcs / package
    16.77£ incl. VAT 13.41£ excl. VAT Add to Cart
  40. 070. Flex pipe

    Flex pipe
    128.88£ incl. VAT 103.10£ excl. VAT Add to Cart
  41. 071. Cu-pipe

    Cu-pipe
    62.32£ incl. VAT 49.85£ excl. VAT Add to Cart
  42. 072. Connection card, sensor

    Connection card, sensor
    92.42£ incl. VAT 73.93£ excl. VAT Add to Cart
  43. 073. Temp sensor, BT10

    Temp sensor, BT10
    39.69£ incl. VAT 31.75£ excl. VAT Add to Cart
  44. 074. Temp sensor, BT11

    Temp sensor, BT11
    40.50£ incl. VAT 32.40£ excl. VAT Add to Cart
  45. 075. Temp sensor, BT12

    Temp sensor, BT12
    43.94£ incl. VAT 35.15£ excl. VAT Add to Cart
  46. 076. Temp Sensor Kit

    Temp sensor kit
    44.14£ incl. VAT 35.31£ excl. VAT Add to Cart
  47. 077. Temp Sensor Kit

    Temp sensor kit
    44.14£ incl. VAT 35.31£ excl. VAT Add to Cart
  48. 078. Temp Sensor Kit

    Temp sensor kit
    44.14£ incl. VAT 35.31£ excl. VAT Add to Cart
  49. 079. Temp Sensor bt3 Res.d

    Temp sensor BT3
    17.88£ incl. VAT 14.30£ excl. VAT Add to Cart
  50. 080. Slider

    Slider
    16.77£ incl. VAT 13.41£ excl. VAT Add to Cart
  51. 082. Flexible pipe, compressor

    Flexible pipe
    160.69£ incl. VAT 128.55£ excl. VAT Add to Cart
  52. 083. Flexible pipe

    Flexible pipe
    95.24£ incl. VAT 76.19£ excl. VAT Add to Cart
  53. 084. Flexible pipe

    Flexible pipe
    147.26£ incl. VAT 117.81£ excl. VAT Add to Cart
  54. 085. Vessel, complete

    Vessel, complete
    110.39£ incl. VAT 88.31£ excl. VAT Add to Cart
  55. 086. Flexible pipe

    Flexible pipe
    124.94£ incl. VAT 99.95£ excl. VAT Add to Cart
  56. 095. Damper for dischargeline

    Damper for dischargeline
    16.77£ incl. VAT 13.41£ excl. VAT Add to Cart
  57. 097. Soft starter 3x400v, 60hm

    Soft starter 3x400v, 60hm
    253.01£ incl. VAT 202.40£ excl. VAT Add to Cart
  58. 099. Cable, motor 3x400V

    Cable, motor 3x400V
    124.43£ incl. VAT 99.55£ excl. VAT Add to Cart
  59. 105. Gasket kit, O-rings 26,65x2,62

    Gasket kit, O-rings 26,65x2,62
    16.77£ incl. VAT 13.41£ excl. VAT Add to Cart
  60. 109. Cable kit, basic module F11

    Cable kit, basic module F11
    136.96£ incl. VAT 109.56£ excl. VAT Add to Cart
  61. 125. Top panel

    Top panel
    85.04£ incl. VAT 68.03£ excl. VAT Add to Cart
  62. 126. Side plate (L)

    Side plate (L)
    124.94£ incl. VAT 99.95£ excl. VAT Add to Cart
  63. 127. Side plate (R)

    Side plate (R)
    124.94£ incl. VAT 99.95£ excl. VAT Add to Cart
  64. 128. Front, complete

    Front, complete
    266.64£ incl. VAT 213.31£ excl. VAT Add to Cart
  65. 129. Front door

    Front door
    167.86£ incl. VAT 134.29£ excl. VAT
